Quine in Whitespace

Welcome to the Quine in Whitespace page! Here, you'll find the source code for this program as well as a description of how the program works.

Current Solution

Quine in Whitespace was written by:

• rzuckerm

This article was written by:

• rzuckerm

If you see anything you'd like to change or update, please consider contributing.

How to Implement the Solution

The code listed in the "Current Solution" section looks like a polar bear in a blizzard! In other words, it is nothing but whitespace characters. The reason is two-fold:

1. In Whitespace, the only characters that contain instructions are whitespace characters. Everything else is ignored.
2. While it is possible to write a program that generates comments or other annotation, it would require a lot more code to do so. It is easier to just generate the whitespace characters that represent the code.

At the highest level, the code consists of the following:

• Push P (an integer value that represents the rest of the code) onto the stack.
• The rest of the code (for brevity, let's call this R).

The value of P is calculated by representing each whitespace character in R as a base-3 number, least-significant value first, where:

• 0 = space
• 1 = tab
• 2 = linefeed

In other words:

• P = 3⁰r₁ + 3¹r₂ + 3²r₃ + … + 3^T-1r_T

where:

• T is the number of values in R.
• r_i is the ith value of R.

P is a very large number: 125 base-10 digits!

So how does this approach generate an output that is identical to the actual program file? The idea is based on a description in RosettaCode (the code is not present since it looks like RosettaCode trims whitespace, and the code is all whitespace). Let's break it down. The rest of the code, R, does this:

• Output the Push instruction as whitespace characters.
• Output P as whitespace characters.

The Push instruction consists of the following:

• The Push opcode: space, space
• The sign bit of P (0 for positive): space
• The value of P in base-2, most-significant bit first: space for 0, tab for 1
• The terminator for the Push instruction: newline

Outputting the Push instruction consists of the following:

• Output 3 spaces for the opcode and sign bit.
• Output the value of P as whitespace characters.
• Output linefeed.

In order to easily translate integers into whitespace characters, memory (mem) is set up as follows:

• mem[0] = space
• mem[1] = tab
• mem[2] = linefeed

Outputting the value of P as whitespace characters is done like this:

• Find D = 2^K such that D is greater than or equal to P:

  D = 1
  Do
    D = D * 2
  While D < P


• Output P in base-2, most-significant bit first, translated to whitespace characters:

  While (D = D // 2) != 0
    N = P // D
    Output mem[N % 2]
  End While


  where // means integer division, and % means modulo.

Outputting the rest of the program as whitespace characters consists of this:

• Output P in base-3, least-significant value first, translated to whitespace characters:

  While P != 0
    Output mem[P % 3]
    P = P // 3
  End While


To balance out the stack and end the program, there is a Pop instruction and an End instruction that tells the Whitespace interpreter to end the program, but those are already accounted for in the value of P.

To see this all together, take a look at the Whitespace Assembly Code that was used to generate this sample. The Whitespace Assembly Language was converted to whitespace characters using the Whitespace Assembler. This sample is the output of the Assembler.

How to Run the Solution

To run this program:

• Download a copy of Quine in Whitespace.
• Browse to the Try It Online Whitespace Interpreter.
• Open the code in an editor, select all, and copy the code to the clipboard.
• Paste it into the Code section in the browser window. The size of the code should be 679 bytes. If it is less, scroll all the way to the bottom and press Enter.
• Press the "Play" button at the top of the browser window to run the code.
• The Output section at the bottom should be identical to the original code.
